Lenovo Intel Xeon Silver 4210R processor 2.4 GHz 13.75 MB
Product Technical Specification
Processor | |
Processor manufacturer | Intel |
Processor generation | Intel Xeon Scalable 2nd Gen |
Processor model | 4210R |
Processor base frequency | 2.4 |
Processor family | Intel Xeon Silver |
Processor cores | 10 |
Processor socket | LGA 3647 (Socket P) |
Component for | Server/Workstation |
Processor lithography | 14 |
Processor threads | 20 |
Processor operating modes | 64-bit |
Processor boost frequency | 3.2 |
Processor cache | 13.75 |
Thermal Design Power (TDP) | 100 |
Box | No |
Cooler included | No |
Processor codename | Cascade Lake |
Processor ARK ID | 197098 |
Memory | |
Maximum internal memory supported by processor | 1024 |
Memory types supported by processor | DDR4-SDRAM |
Memory clock speeds supported by processor | 2400 |
Memory channels | Hexa-channel |
ECC | Yes |
Graphics | |
On-board graphics card | No |
Discrete graphics card | No |
On-board graphics card model | Not available |
Discrete graphics card model | Not available |
Features | |
Execute Disable Bit | Yes |
Market segment | Server |
Maximum number of PCI Express lanes | 48 |
PCI Express slots version | 3.0 |
Supported instruction sets | AVX,AVX 2.0,AVX-512,SSE4.2 |
Scalability | 2S |
Embedded options available | Yes |
PCI Express CEM revision | 3.0 |
Processor special features | |
Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel Trusted Execution Technology | Yes |
Intel® Speed Shift Technology | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel 64 | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel Turbo Boost Max Technology 3.0 | No |
AVX-512 Fused Multiply-Add (FMA) units | 1 |
Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
Intel® Speed Select technology - Performance Profile (Intel® SST-PP) | No |
Intel® Volume Management Device (VMD) | Yes |
Intel® Optane™ DC Persistent Memory Supported | No |
Intel® vPro™ Platform Eligibility | Yes |
Intel® Speed Select Technology - Base Frequency (Intel® SST-BF) | No |
Operational conditions | |
Tcase | 84 |
Logistics data | |
Harmonized System (HS) code | 85423119 |
Weight & dimensions | |
Processor package size | 76.0 x 56.5 |
Delivery Options
Economy Delivery (UK)
Business Express
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.
Intel® vPro™ Platform Eligibility
Intel® vPro™ Technology is a set of security and manageability capabilities built into the processor aimed at addressing four critical areas of IT security: 1) Threat management, including protection from rootkits, viruses, and malware 2) Identity and web site access point protection 3) Confidential personal and business data protection 4) Remote and local monitoring, remediation, and repair of PCs and workstations.
Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.
Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Intel® VT-x with Extended Page Tables (EPT)
Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.
Intel® 64
Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.
Instruction Set
An instruction set refers to the basic set of commands and instructions that a microprocessor understands and can carry out. The value shown represents which Intel’s instruction set this processor is compatible with.
Instruction Set Extensions
Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).
# of AVX-512 FMA Units
Intel® Advanced Vector Extensions 512 (AVX-512), new instruction set extensions, delivering ultra-wide (512-bit) vector operations capabilities, with up to 2 FMAs (Fused Multiply Add instructions), to accelerate performance for your most demanding computational tasks.
Enhanced Intel SpeedStep® Technology
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.
Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.
Intel® Resource Director Technology (Intel® RDT)
Intel® RDT brings new levels of visibility and control over how shared resources such as last-level cache (LLC) and memory bandwidth are used by applications, virtual machines (VMs) and containers.
Intel® Volume Management Device (VMD)
Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.
